Viega Smartpress – efficient installations with superior hygiene

Use

To accommodate all structural conditions and desired connection variants, Viega Smartpress offers a complete range of connectors for drinking water and heating installations.
Viega SC-Contur

The Viega SC-Contur is one of the most significant safety improvements in press connection technology. It makes it easy to detect inadvertently unpressed connections.
No sealing elements

A connection without any sealing element is more secure. There is no O-ring to damage. The absence of a sealing element also minimises the reduction in cross-section in the connection.
Low zeta values

Flow-optimised press connectors with low zeta values for minimal pressure loss, improved drinking water hygiene and reduced ejection times.
Material

The complete system consists of flexible multi-layer pipe with matching metal press connectors made of stainless steel and gunmetal.
Quick assembly

Only three steps are necessary: cut the pipe to length, fit the connector, press it into place – job done. No need for time-consuming calibration.

The flow-optimised system – without an O-ring

Viega Smartpress is setting new standards in flexible floor installation. Viega Smartpress press connectors use tried-and-tested, durable materials such as stainless steel and gunmetal, and do their job without the need for O-rings. The result? Low pressure losses, smaller pipe dimensions and no more time-consuming calibration. Viega Smartpress is a product of the highest quality that combines dimensional stability with flexibility. It has optimum flow properties with low zeta values and enables quick, safe and convenient installation. Immerse yourself in the future of multi-layer pipe installation with Viega Smartpress.

Three reasons for using Viega Smartpress for heating installations
Time-saving solution for heating installations
Can be used flexibly as a riser pipe or a floor installation solution
Extensive range of accessories for flexible and fast radiator connection
Close

Three reasons for using Viega Smartpress for drinking water installations
Extensive range of stainless steel and gunmetal connectors for any installation
Zeta-optimised component geometry
Long-term safety coupled with maximum hygiene
Close

Use for heating installations

Areas of application

Special features of the Viega Smartpress system

Minimal effort required, optimum flow properties

Viega Smartpress offers all the same advantages as a plastic system. Its stainless steel and gunmetal connectors are hygienic and enable the efficient installation of drinking water systems. The flow-optimised connectors make it possible to reduce the volume of water and the risk of stagnation. The O-ring-free connection technology ensures safety, as there is no longer any O-ring at risk of getting soiled, becoming damaged or slipping out of place. Nor is there any need for time-consuming calibration work. This makes installation up to 30 % faster.

Viega Smartpress pipe – flexible and dimensionally stable

Viega Smartpress pipes are flexible and dimensionally stable, and are available in sizes from 16 to 63 mm. The pipes ranging from 16 to 32 mm in size can be easily bent by hand. Their sophisticated structure comprising a plastic inliner, aluminium and a plastic outer sheath ensures small bending radii and high kink resistance. This flexibility is particularly suitable for confined installation spaces and makes it possible to save on moulded pieces.

Hygienic drinking water installations

Viega Smartpress is ideal for hygienically demanding environments such as hospitals or care facilities. The flow-optimised connectors enable standard-compliant installations in complex situations and promote regular water exchange. This reduces the risk of stagnation and microbial contamination. Viega Smartpress supports both ring systems and series pipelines, as well as T-piece installations, while reducing the quantity of materials used and ensuring the highest drinking water quality.

Viega Smartpress for heating installations

Viega Smartpress is oxygen-tight, making it ideal for heating installations. Not only that, but the press connector system saves you both time and money. In addition to its flexible, dimensionally stable multi-layer pipes and high-quality stainless steel and gunmetal press connectors, it also offers every other conceivable component – from radiator connection blocks to euro cone connection screw fittings. Available in dimensions ranging from 16 to 63 mm, it can accommodate applications of any kind.

The Viega Smartpress assembly process – quick, clean and safe 

The insertion depth of the press connector is marked on the end of the pipe.

Step 1

Cut the pipe

Cut the pipe to length using pipe shears. After that, no further calibration is required.

Step 2

Fit the press connector

Attach the press connector to the pipe and apply the press jaw. No expansion or calibration is necessary, as all components are pre-assembled. No additional tools are required. A window allows the insertion depth to be checked before and after pressing.

Step 3

Press

Use a Viega Pressgun or the Viega Smartpress hand press tool to establish a force-fit connection between the press connector and pipe. Once again, the SC-Contur is there to ensure maximum safety.

And that’s it!

The result is a tight and secure connection that is immediately ready to bear the full load.

1 / 4

Click here for the instructions for use

The Viega Smartpress product range

The wide Viega Smartpress product range is ideal for drinking water and heating systems in residential and industrial buildings.

It combines flexible multi-layer pipes (16 to 63 mm) with stainless steel and gunmetal press connectors. The stand-out feature of Viega Smartpress is its flow-optimised, O-ring-free connection technology . This ensures low pressure losses and easy installation. It meets the requirements of all relevant standards and certifications for drinking water and heating installations.

Assembly is quick and efficient with the Viega Pressgun or Viega Smartpress hand press tool. Viega Smartpress is synonymous with efficiency, reliability and easy handling.

You can find more detailed information about the Viega Smartpress product range here:
