Viega Sanpress Inox – durable quality and high flexibility
When maximum hygiene is required
In hygienically sensitive areas such as hospitals or food processing factories, stainless steel press connector systems are always the best choice. Viega Sanpress Inox is a complete stainless steel system comprising press connectors and piping of the highest quality. The extensive range of parts and components enables you to create installations for drinking water and industrial applications that incorporate long-term safety, from the riser pipe to the final draw-off point. This makes Viega Sanpress Inox the answer to virtually any challenge when installing drinking water systems.
Areas of application
Drinking water
Compressed air
Solar
Special features of the Sanpress Inox system
High-quality stainless steel for demanding environments – certified according to DVGW standards
The components of Viega Sanpress Inox are made of the resilient 1.4401 and 1.4521 stainless steel materials, making them suitable for use under extremely demanding conditions as well. As a result, there is no barrier to using Viega Sanpress Inox in the healthcare or industrial sectors. The system has been independently certified as compliant with Kiwa Regulation 4 (KUKreg4), ÖVGW guidelines and DVGW worksheets GW 541 and W 534, thereby providing an assurance of its long-term safety and reliability with regard to drinking water quality.
%3Athumb-ultrawide "Example image Viega SC-Contur")
Viega Sanpress Inox – a system that is adaptable thanks to its wide product range
Viega Sanpress Inox offers a diverse array of stainless steel press connectors and other system components made of stainless steel. This allows flexible installations and provides the right solution for any requirements. The complete drinking water installation can be realised with the Viega Sanpress Inox system – from the riser pipe to the final draw-off point – even when the installation situation is challenging. Whether you are aiming to connect the various draw-off points with a ring system, a series pipeline featuring a circulation connection of a classic T-piece installation, Viega Sanpress Inox has the right components for virtually any conceivable application in dimensions from 15 to 108 mm.
Quality and extreme durability – Viega Sanpress Inox pipes
The Viega Sanpress Inox 1.4521 pipe is characterised by its first-class quality and remarkable durability. As a material, grade 1.4521 steel has a higher chromium and molybdenum content, and benefits from dual stabilisation with titanium and niobium. This results in a PREN (pitting resistance equivalent number) of > 24 – clearly demonstrating the material’s exceptional resistance. A modern laser welding process without any filler materials is used for production, which enables the creation of narrow weld seams.
Viega Sanpress Inox XL – versatile solutions in a large format
The Sanpress Inox stainless steel press connectors are also available in the larger dimensions of 64, 76.1, 88.9 and 108 mm, and are used in a wide range of building services and industrial applications. The XL versions are characterised by their high level of practicality and extensive product range. Consequently, they can be used even under challenging spatial conditions. The product range includes XL slip couplings, flanges from DN 60 to DN 100, and many other adapter solutions for the straightforward installation of water filters, fittings or measuring devices, for example. A special feature is the 64 mm dimension, which bridges the gap between the 54 and 76.1 mm diameters. In the long term, this avoids the extra costs that could otherwise result from installing oversized nominal widths.
Smartloop inliner technology
Sufficient circulation – usually through a separate pipe next to the hot water pipe – is important for maintaining constant temperatures when distributing hot water. The Smartloop inliner technology combines the supply and return flow in one pipe, eliminating the need for an additional pipe. The advantages are less heat loss, reduced material and assembly expenditure and lower pipe insulation costs. Viega offers all the components required to achieve a circulation concept that saves space and resources. Click here to find out more about Smartloop inliner technology.
Advantages of press connection technology at a glance
Time savings
Using the pressing technique to connect piping reduces installation time significantly. Much less effort is required compared to conventional methods such as welding or soldering and it can even be used in hard-to-reach areas. The system elements can be joined together in less than 20 seconds, reducing assembly time by up to 80 %.
Reliability
With our stringent quality standards, high-quality materials and continuous innovations, we ensure reliable press connections. The Viega SC-Contur feature makes any inadvertently unpressed connections clearly visible. It is included in all press connectors and enables a centralised leakage test to be performed.
Cost efficiency
The perfect symbiosis of quality and economic efficiency. Viega press connection technology is the effective way to save time and money. Not only does it eliminate the special steps associated with processes such as welding or soldering, but the pressing method also makes the system less prone to faults and therefore more durable than the alternatives.
Safety
No flames or fumes are generated when pressing pipe connections and the process is absolutely fireproof. This reduces the risks posed by flying sparks or human error – a major advantage, especially in sensitive or hard-to-reach environments. It also minimises the need for special health and safety measures and permits.
The Sanpress Inox assembly process – quick, clean and safe
The Sanpress Inox product range
With over 800 press connectors and components made of high-quality stainless steel (1.4401 and 1.4521), the Sanpress Inox system offers a comprehensive solution for drinking water, heating and cooling systems, particularly in hygienically demanding environments.
Available in dimensions from 15 to 108 mm – including XL versions – it meets the highest quality standards and is certified according to ÖVGW and DVGW requirements.
Thanks to the straightforward installation process using the Viega Pressgun and corresponding pressing jaws, Sanpress Inox is ideal for creating reliable and durable installations in building services and industrial applications.
You can find more detailed information about the Sanpress Inox product range here:
Certificates
Sanpress Inox has been certified by the following institutions:
